Easynav Infinity Surgical System by Shreya Paliwal is a highly esteemed winner of the very prestigious 2022 A' Design Award in Medical Devices and Medical Equipment Design Competition Category.
IronMedical Product· 2022
Easynav Infinity Surgical System
Client: Happy Reliable Surgeries Pvt. Ltd
A' Design Award Winner in Medical Product Category
Verified Award Winner
Verify Award Status for #139427The Design
About Easynav Infinity Surgical System
The design of Infinity is Visual Reflection of quality of product using unique form language which has also been optimized for manufacturing and cost effectiveness. Generally, the relevant market segment is filled with product that are designed using plastics to achieve difficult curves and form language which feels appealing to the user and comfortable to the patient. It had been a design challenge for the designer to create a unique form factor using only sheet metal and subsequent processes while also keeping in mind the cost for a unique product as such having low-volume production.
The Recognition
About the A' Design Award
Easynav Infinity Surgical System is an Iron A' Design Award winner, a prestigious recognition granted to good designs that meet the professional and industrial requirements expected from well-designed creations. Iron winners demonstrate great skill, high specialization, expert understanding, and creative capacity of their creators. Easynav Infinity Surgical System is expected to be a highly regarded, admired, and cherished creation that is practical and innovative. This Iron A' Design Award-winning design integrates industry best practices and has competent technical characteristics linked with know-how and talent. Easynav Infinity Surgical System is respected for its thoroughness and is designed to provide quality of life improvements that help make the world a better place.
Interviews
Design Interview
What is the main principle, idea and inspiration behind your design?
Visual Reflection of quality of product using unique form language which is also optimized for manufacturing and cost-effectiveness. Generally, the market segment is filled with products designed using plastics or thermoforming to achieve difficult curves and form language that feels appealing to the user and comfortable to the patient. We have challenged the market by creating a unique form factor using sheet metal thereby optimizing the cost for such a product with low volume production.
What has been your main focus in designing this work? Especially what did you want to achieve?
The main focus was to build a unique product that challenges the assumption "good curves and unique form language can only be achieved using processes like thermoforming, die casting, and so on". Using only sheet metal, a few bending, welding, and finishing processes Infinity has set itself apart in the market.
What are your future plans for this award winning design?
Refining it further to ensure best possible Navigational experience during the surgery while also enhancing the System of products for the Patients undergoing the surgery.
Behind the Design
Press Kit
Credits, team members and technical details provided by the designer.
- Unique Properties
- The design ensures visual reflection of the quality of the product using unique form language while also being optimized for manufacturing and cost. It challenges the assumption that good curves and unique form language can only be achieved using processes like thermoforming, die casting, and so on. Infinity sets itself apart in the market with a unique form factor achieved using only sheet metal, a few bending, welding, and finishing processes.
- Dimensions & Packaging
- The dimensions are product dimensions excluding the height of the camera and monitor
Dimensions: 457.2mm x 245.5mm x 927.2 mm
Material : Stainless Steel, 2 mm in thickness
Processes used: Laser cutting, Sheet metal Bending, Lancing, Welding, Buffing and Powder coating - Tags
- Futuristic, Medical device, User friendly, Robotic, Elegant, Soothing
- Production Technology
- Infinity has Nerves of Steel, the product is made of sheet metal, Stainless Steel - to avoid any rusting, and has been optimized such that the manufacturing takes less time, and resources. The unique taper shape, curves along the body and the handle are achieved using modifications done to the bending tools and development techniques without any plastic components. Laser cutting, lancing, and bending operations are done following which welding, buffing, and powder coating is required.
- Design Challenge
- Most of the market in the surgical navigation segment has aesthetic forms that are manufactured using a combination of thermoformed plastics and sheet metal parts. Competing within the same segment while providing cost-effective solutions with unique design, premium experience, and without using plastics had been a challenge. The Interface had been created using a software with limited creative implementation capabilities so the design had to be optimized for fewer efforts and more impact.
- Research
- Qualitative Research was used to uncover areas of improvement in customer interaction, product safety, design language, overall experience, manufacturability, cost, and assembly of the product. After feedbacks and interviews with surgeons, OT staff, Team at HRS and experts from the domain, Investigator Triangulation had been used to validate the data points. Implementation of these insights into the design resulted in a Positive Change in the Perception of Product Quality hence Brand Positioning.
- Inspiration
- While working in the field of medical technology, customer satisfaction and the comfort of the patient is very important. Aesthetical beauty with a seamless product experience is an integral factor that helps achieve it. The previous model of the product had inherent quality and accuracy but lacked the visual factors to appeal and compete in the market. Hailing from a family of doctors, the empathy towards doctors and patients became a strong motive to re-design the product system.
- Project Duration
- The project started in October 2020 and has undergone three iterations and testing before reaching this final version in Feb 2022
- Operation Flow
- First, the product is assembled, sanitized, and made ready for the users to interact with. Then surgical data of the patient is added to generate a three dimensional model of the scans. Infinity allows for preoperative planning, enabling the surgeon to view the data and plan the course of surgery before making an incision. The system is then calibrated in relation to the body of the patient, to give accurate real time data for navigating toward the desired area with safety and ease.
- Team Members
- Mentor: Arpit Paliwal
Mentor: Parag K Vyas - Image Credits
- Image #1: Designer Shreya Paliwal, easyNav Infinity 1, 2022.
Image #2: Designer Shreya Paliwal, easyNav Infinity 2, 2022.
Image #3: Designer Shreya Paliwal, easyNav Infinity 3, 2022.
Image #4: Designer Shreya Paliwal, easyNav Infinity 4, 2022.
Image #5: Designer Shreya Paliwal, easyNav Infinity 5, 2022.
Video Credits: Happy Reliable Surgeries Pvt. Ltd, Infinity Video, 2022
