HSR048, HSR050 and HSR060 are horizontal multi-joint industrial robots, also known as Scara robots. Each robot holds a hand at the arm tip, so the machine can be adapted to many tasks and supports automation and labor saving in production plants. The arms extend from a stable base and become slimmer toward the tip, which lowers weight and inertia and allows stable high-speed motion. The organic form recalls the human body and makes fast movement less intimidating for workers on the production line. The compact body helps reduce the size of the equipment.
